こんにちは。サイオステクノロジー OSS サポート担当 Y です。

今回は、PostgreSQL 11 にて postgres_fdw (外部テーブル) を利用したパーティションテーブルと、ローカルで作成した (外部テーブルを利用せず、同一サーバ上で作成した) パーティションテーブルの動作を検証してみました。(※以下の内容は CentOS 7.6/PostgreSQL 10.6/PostgreSQL 11.1 にて検証しています。)

■はじめに

前回の記事では、PostgreSQL 11 にて postgres_fdw (外部テーブル) を利用したパーティションテーブルの作成と、親テーブルからのデータの INSERT を検証してみました。

今回は、postgres_fdw (外部テーブル) を利用したパーティションテーブルと、ローカルで作成した (外部テーブルを利用せず、同一サーバ上で作成した) パーティションテーブルで UPDATE を実行した際の動作の違いについて検証してみました。

■環境構成

それではさっそく、検証してみます。

今回は以下の様な構成の 2つのパーティションテーブル (RANGE パーティション) を作成します。(外部テーブルを利用したパーティションテーブルの作成については、前回の記事を参照して下さい。)

[サーバ構成 (外部テーブルを利用)]
----------------------------------------------------------------------
                                               +--> [pgsql11_child1.example.com]
[pgsql11_parent.example.com] --(postgres_fdw)--+--> [pgsql11_child2.example.com]
                                               +--> [pgsql11_child3.example.com]
----------------------------------------------------------------------

[テーブル構成 (外部テーブルを利用)]
----------------------------------------------------------------------
                                             +--> [子テーブル (foreign_hoge_1)]
[親テーブル (foreign_hoge)] --(postgres_fdw)--+--> [子テーブル (foreign_hoge_2)]
                                             +--> [子テーブル (foreign_hoge_3)]
----------------------------------------------------------------------
[サーバ構成 (同一サーバ上に各テーブルを作成)]
----------------------------------------------------------------------
                               +--> [pgsql11_parent.example.com]
[pgsql11_parent.example.com] --+--> [pgsql11_parent.example.com]
                               +--> [pgsql11_parent.example.com]
----------------------------------------------------------------------


[テーブル構成 (同一サーバ上に各テーブルを作成)]
----------------------------------------------------------------------
                           +--> [子テーブル (local_hoge_1)]
[親テーブル (local_hoge)] --+--> [子テーブル (local_hoge_2)]
                           +--> [子テーブル (local_hoge_3)]
----------------------------------------------------------------------

■ローカルでのパーティションテーブル作成

外部テーブルを利用したパーティションテーブルは前回の記事で作成したものをそのまま利用するため、今回はローカル (同一サーバ上) でのパーティションテーブルを追加で作成します。

以下の様に、親テーブル/子テーブルを作成します。

[postgres@pgsql11_parent ~]$ psql -c "CREATE TABLE local_hoge (key int, data text) PARTITION BY RANGE (key)"
CREATE TABLE
[postgres@pgsql11_parent ~]$
[postgres@pgsql11_parent ~]$ psql -c "CREATE TABLE local_hoge_1 PARTITION OF local_hoge FOR VALUES FROM (1) TO (4)"
CREATE TABLE
[postgres@pgsql11_parent ~]$
[postgres@pgsql11_parent ~]$ psql -c "CREATE TABLE local_hoge_2 PARTITION OF local_hoge FOR VALUES FROM (4) TO (7)"
CREATE TABLE
[postgres@pgsql11_parent ~]$
[postgres@pgsql11_parent ~]$ psql -c "CREATE TABLE local_hoge_3 PARTITION OF local_hoge FOR VALUES FROM (7) TO (10)"
CREATE TABLE
[postgres@pgsql11_parent ~]$
[postgres@pgsql11_parent ~]$ psql -c "\d+ local_hoge"
                                 Table "public.local_hoge"
 Column |  Type   | Collation | Nullable | Default | Storage  | Stats target | Description
--------+---------+-----------+----------+---------+----------+--------------+-------------
 key    | integer |           |          |         | plain    |              |
 data   | text    |           |          |         | extended |              |
Partition key: RANGE (key)
Partitions: local_hoge_1 FOR VALUES FROM (1) TO (4),
            local_hoge_2 FOR VALUES FROM (4) TO (7),
            local_hoge_3 FOR VALUES FROM (7) TO (10)

これで、ローカルでのパーティションテーブルの作成は完了です。

■データの INSERT

さて、現在検証用のサーバ (PostgreSQL 11) 上には、前述した方法で作成したパーティションテーブル (ローカルに作成) と、前回作成したパーティションテーブル (外部テーブルを利用) が存在しています。(基本的に、テーブルの定義は同じです。)

postgres=# \d
                 List of relations
 Schema |      Name      |     Type      |  Owner
--------+----------------+---------------+----------
 public | foreign_hoge   | table         | postgres
 public | foreign_hoge_1 | foreign table | postgres
 public | foreign_hoge_2 | foreign table | postgres
 public | foreign_hoge_3 | foreign table | postgres
 public | local_hoge     | table         | postgres
 public | local_hoge_1   | table         | postgres
 public | local_hoge_2   | table         | postgres
 public | local_hoge_3   | table         | postgres
(8 rows)

postgres=#
postgres=# \d+ foreign_hoge
                                Table "public.foreign_hoge"
 Column |  Type   | Collation | Nullable | Default | Storage  | Stats target | Description
--------+---------+-----------+----------+---------+----------+--------------+-------------
 key    | integer |           |          |         | plain    |              |
 data   | text    |           |          |         | extended |              |
Partition key: RANGE (key)
Partitions: foreign_hoge_1 FOR VALUES FROM (1) TO (4),
            foreign_hoge_2 FOR VALUES FROM (4) TO (7),
            foreign_hoge_3 FOR VALUES FROM (7) TO (10)

postgres=#
postgres=# \d+ local_hoge
                                 Table "public.local_hoge"
 Column |  Type   | Collation | Nullable | Default | Storage  | Stats target | Description
--------+---------+-----------+----------+---------+----------+--------------+-------------
 key    | integer |           |          |         | plain    |              |
 data   | text    |           |          |         | extended |              |
Partition key: RANGE (key)
Partitions: local_hoge_1 FOR VALUES FROM (1) TO (4),
            local_hoge_2 FOR VALUES FROM (4) TO (7),
            local_hoge_3 FOR VALUES FROM (7) TO (10)

これらのテーブルに対して、それぞれテスト用のデータを INSERT します。

postgres=# INSERT INTO foreign_hoge SELECT a, md5(clock_timestamp()::text) FROM generate_series(1,9) AS a;
INSERT 0 9
postgres=#
postgres=# SELECT * FROM foreign_hoge;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   2 | 0a234b4c35d32fd8583bd578d5bc2446
   3 | a385f544a0e4442100f60194a94b45a7
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | 7103e14f72db14d0715475acfa4ff16f
   6 | a844c1c49c5296b7b0989121a46cebbc
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | c080bac4339edeefad0a3e92b5f86fec
   9 | 93262647cc75b6901d44369d0de4373e
(9 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_1;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   2 | 0a234b4c35d32fd8583bd578d5bc2446
   3 | a385f544a0e4442100f60194a94b45a7
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_2;
 key |               data
-----+----------------------------------
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | 7103e14f72db14d0715475acfa4ff16f
   6 | a844c1c49c5296b7b0989121a46cebbc
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_3;
 key |               data
-----+----------------------------------
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | c080bac4339edeefad0a3e92b5f86fec
   9 | 93262647cc75b6901d44369d0de4373e
(3 rows)
postgres=# INSERT INTO local_hoge SELECT a, md5(clock_timestamp()::text) FROM generate_series(1,9) AS a;
INSERT 0 9
postgres=#
postgres=# SELECT * FROM local_hoge;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | a7e902a628541d2db2248261b4ded233
   3 | 60048e7fd0b0607e2c510a84351ee5e7
   4 | dff554c90afed584239fab122f412168
   5 | a74107d25fe744e7b0b6e429294a1f78
   6 | 8a896920b5e331768cc17761eb49ab8d
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   8 | 2a62a81f178ef15dad965eaf8ca0c211
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(9 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_1;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | a7e902a628541d2db2248261b4ded233
   3 | 60048e7fd0b0607e2c510a84351ee5e7
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_2;
 key |               data
-----+----------------------------------
   4 | dff554c90afed584239fab122f412168
   5 | a74107d25fe744e7b0b6e429294a1f78
   6 | 8a896920b5e331768cc17761eb49ab8d
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_3;
 key |               data
-----+----------------------------------
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   8 | 2a62a81f178ef15dad965eaf8ca0c211
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(3 rows)

上記の様に INSERT/SELECT に関しては、どちらのパーティションテーブルでも問題なく実施することができました。

次に、パーティションキー以外のカラム (data) の値を UPDATE してみます。

postgres=# UPDATE foreign_hoge SET data = 'foreign hogehoge' WHERE key = 2;
UPDATE 1
postgres=#
postgres=# UPDATE foreign_hoge SET data = 'foreign hogehoge' WHERE key = 5;
UPDATE 1
postgres=#
postgres=# UPDATE foreign_hoge SET data = 'foreign hogehoge' WHERE key = 8;
UPDATE 1
postgres=#
postgres=# SELECT * FROM foreign_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   2 | foreign hogehoge
   3 | a385f544a0e4442100f60194a94b45a7
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | foreign hogehoge
   6 | a844c1c49c5296b7b0989121a46cebbc
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | foreign hogehoge
   9 | 93262647cc75b6901d44369d0de4373e
(9 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_1 ORDER BY key;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   2 | foreign hogehoge
   3 | a385f544a0e4442100f60194a94b45a7
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_2 ORDER BY key;
 key |               data
-----+----------------------------------
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | foreign hogehoge
   6 | a844c1c49c5296b7b0989121a46cebbc
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_3 ORDER BY key;
 key |               data
-----+----------------------------------
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | foreign hogehoge
   9 | 93262647cc75b6901d44369d0de4373e
(3 rows)
postgres=# UPDATE local_hoge SET data = 'local hogehoge' WHERE key = 2;
UPDATE 1
postgres=#
postgres=# UPDATE local_hoge SET data = 'local hogehoge' WHERE key = 5;
UPDATE 1
postgres=#
postgres=# UPDATE local_hoge SET data = 'local hogehoge' WHERE key = 8;
UPDATE 1
postgres=#
postgres=# SELECT * FROM local_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | local hogehoge
   3 | 60048e7fd0b0607e2c510a84351ee5e7
   4 | dff554c90afed584239fab122f412168
   5 | local hogehoge
   6 | 8a896920b5e331768cc17761eb49ab8d
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   8 | local hogehoge
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(9 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_1 ORDER BY key;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | local hogehoge
   3 | 60048e7fd0b0607e2c510a84351ee5e7
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_2 ORDER BY key;
 key |               data
-----+----------------------------------
   4 | dff554c90afed584239fab122f412168
   5 | local hogehoge
   6 | 8a896920b5e331768cc17761eb49ab8d
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_3 ORDER BY key;
 key |               data
-----+----------------------------------
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   8 | local hogehoge
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(3 rows)

パーティションキー以外のカラム (data) の更新も、問題無く実行することができました。

今度は、パーティションキー (key) の値を更新してみます。(先に結論を言ってしまうと、このパーティションキーの値の更新時の動作に一部違いがあります。)

まずは、更新後のパーティションキーの値が、各子テーブルの条件の範囲内 (*_hoge_1 の場合 1 =< key < 4) に収まる様な値に更新してみます。

postgres=# UPDATE foreign_hoge SET key = 1 WHERE key = 3;^C
postgres=#
postgres=# SELECT * FROM foreign_hoge_1;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   3 | a385f544a0e4442100f60194a94b45a7
   2 | foreign hogehoge
(3 rows)

postgres=#
postgres=# UPDATE foreign_hoge SET key = 1 WHERE key = 3;
UPDATE 1
postgres=#
postgres=# SELECT * FROM foreign_hoge_1;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   2 | foreign hogehoge
   1 | a385f544a0e4442100f60194a94b45a7
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   1 | a385f544a0e4442100f60194a94b45a7
   2 | foreign hogehoge
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | foreign hogehoge
   6 | a844c1c49c5296b7b0989121a46cebbc
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | foreign hogehoge
   9 | 93262647cc75b6901d44369d0de4373e
(9 rows)
postgres=# SELECT * FROM local_hoge_1;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   3 | 60048e7fd0b0607e2c510a84351ee5e7
   2 | local hogehoge
(3 rows)

postgres=#
postgres=# UPDATE local_hoge SET key = 1 WHERE key = 3;
UPDATE 1
postgres=#
postgres=# SELECT * FROM local_hoge_1;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | local hogehoge
   1 | 60048e7fd0b0607e2c510a84351ee5e7
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | 60048e7fd0b0607e2c510a84351ee5e7
   1 | 3859054d6ef644ee17995db1abd6184b
   2 | local hogehoge
   4 | dff554c90afed584239fab122f412168
   5 | local hogehoge
   6 | 8a896920b5e331768cc17761eb49ab8d
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   8 | local hogehoge
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(9 rows)

更新後のパーティションキーの値が、各子テーブルの条件の範囲内 (*_hoge_1 の場合 1 =< key < 4) に収まる様な UPDATE は、どちらのパーティションテーブルでも問題なく実行することができました。

次に、更新後のパーティションキーの値が、異なる子テーブルの条件に合致する値になる様な更新を実行してみます。

最初に、外部テーブルを利用したパーティションテーブルにて、*_hoge_2 に格納されている key = 6 のレコードの key の値を “7” (*_hoge_3 の条件に合致する値) に更新します。

postgres=# SELECT * FROM foreign_hoge_2;
 key |               data
-----+----------------------------------
   4 | 76bd4050760e236fe641f423d65ebb66
   6 | a844c1c49c5296b7b0989121a46cebbc
   5 | foreign hogehoge
(3 rows)

postgres=#
postgres=# UPDATE foreign_hoge SET key = 7 WHERE key = 6;
UPDATE 1
postgres=#
postgres=# SELECT * FROM foreign_hoge_2;
 key |               data
-----+----------------------------------
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | foreign hogehoge
   7 | a844c1c49c5296b7b0989121a46cebbc
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge_3;
 key |               data
-----+----------------------------------
   7 | 6d17cfaa36065b62f30532d0c6a84009
   9 | 93262647cc75b6901d44369d0de4373e
   8 | foreign hogehoge
(3 rows)

postgres=#
postgres=# SELECT * FROM foreign_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | f4a623ee2ad94ef7132b929e2d31ff81
   1 | a385f544a0e4442100f60194a94b45a7
   2 | foreign hogehoge
   4 | 76bd4050760e236fe641f423d65ebb66
   5 | foreign hogehoge
   7 | a844c1c49c5296b7b0989121a46cebbc
   7 | 6d17cfaa36065b62f30532d0c6a84009
   8 | foreign hogehoge
   9 | 93262647cc75b6901d44369d0de4373e
(9 rows)

すると、key の値の UPDATE 自体は正常に実行されましたが、子テーブル間でのレコードの移動は行われず、子テーブル foreign_hoge_2 の中に条件 (4 <= key < 7) に合致しないレコード (key = 7) が格納されている状態になりました。

次に、ローカルのパーティションテーブル (外部テーブルを利用していないパーティションテーブル) にて、同じ様に *_hoge_2 に格納されている key = 6 のレコードの key の値を “7” (*_hoge_3 の条件に合致する値) に更新してみます。

postgres=# SELECT * FROM local_hoge_2;
 key |               data
-----+----------------------------------
   4 | dff554c90afed584239fab122f412168
   6 | 8a896920b5e331768cc17761eb49ab8d
   5 | local hogehoge
(3 rows)

postgres=#
postgres=# UPDATE local_hoge SET key = 7 WHERE key = 6;
UPDATE 1
postgres=#
postgres=# SELECT * FROM local_hoge_2;
 key |               data
-----+----------------------------------
   4 | dff554c90afed584239fab122f412168
   5 | local hogehoge
(2 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_3;
 key |               data
-----+----------------------------------
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
   8 | local hogehoge
   7 | 8a896920b5e331768cc17761eb49ab8d
(4 rows)

postgres=#
postgres=# SELECT * FROM local_hoge ORDER BY key;
 key |               data
-----+----------------------------------
   1 | 3859054d6ef644ee17995db1abd6184b
   1 | 60048e7fd0b0607e2c510a84351ee5e7
   2 | local hogehoge
   4 | dff554c90afed584239fab122f412168
   5 | local hogehoge
   7 | 3c851f729dc6c384d708d9df4d9c16d4
   7 | 8a896920b5e331768cc17761eb49ab8d
   8 | local hogehoge
   9 | a65ebec1f7b2f6d775aec593c4c70ba7
(9 rows)

すると今度は、子テーブル間でレコードが移動し、子テーブル local_hoge_2 の中から key = 6 だったレコード (data = ‘8a896920b5e331768cc17761eb49ab8d’ のレコード) が消え、local_hoge_3 に UPDATE 後の key = 7 のレコード (data = ‘8a896920b5e331768cc17761eb49ab8d’ のレコード) が格納されている状態になりました。

上記の様にパーティションキーの値を UPDATE した場合、ローカルのパーティションテーブルであれば、条件に合致する子テーブルに自動的にレコードを移動してくれます。

しかし、外部テーブルを利用したパーティションテーブルの場合、条件に合致する子テーブルへのレコードの移動は実施されません。

現時点 (PostgreSQL 11) における外部テーブルを利用したパーティションテーブルには、上記の様な制約があるようです。

私の個人的な見解ですが、外部テーブルを利用したパーティションテーブルの場合、複数ノードに跨る様なトランザクションを管理する (複数ノード間で原始性等を担保する) ための、2層 COMMIT のような仕組みがまだ実装されていないため、このような動作になっているのではないかと推測しています。

■おまけ

ちなみに、PostgreSQL 10 の場合はローカルのパーティションテーブルであっても、更新後のパーティションキーの値が、異なる子テーブルの条件に合致する様な更新を実行しようとすると、以下の様にエラーになってしまいます。

[postgres@pgsql10_parent ~]$ psql -c "CREATE TABLE local_hoge (key int, data text) PARTITION BY RANGE (key)"
CREATE TABLE
[postgres@pgsql10_parent ~]$
[postgres@pgsql10_parent ~]$ psql -c "CREATE TABLE local_hoge_1 PARTITION OF local_hoge FOR VALUES FROM (1) TO (4)"
CREATE TABLE
[postgres@pgsql10_parent ~]$
[postgres@pgsql10_parent ~]$ psql -c "CREATE TABLE local_hoge_2 PARTITION OF local_hoge FOR VALUES FROM (4) TO (7)"
CREATE TABLE
[postgres@pgsql10_parent ~]$
[postgres@pgsql10_parent ~]$ psql -c "CREATE TABLE local_hoge_3 PARTITION OF local_hoge FOR VALUES FROM (7) TO (10)"
CREATE TABLE
[postgres@pgsql10_parent ~]$
[postgres@pgsql10_parent ~]$ psql
psql (10.6)
Type "help" for help.

postgres=#
postgres=# \d+ local_hoge
                                 Table "public.local_hoge"
 Column |  Type   | Collation | Nullable | Default | Storage  | Stats target | Description
--------+---------+-----------+----------+---------+----------+--------------+-------------
 key    | integer |           |          |         | plain    |              |
 data   | text    |           |          |         | extended |              |
Partition key: RANGE (key)
Partitions: local_hoge_1 FOR VALUES FROM (1) TO (4),
            local_hoge_2 FOR VALUES FROM (4) TO (7),
            local_hoge_3 FOR VALUES FROM (7) TO (10)

postgres=#
postgres=# INSERT INTO local_hoge SELECT a, md5(clock_timestamp()::text) FROM generate_series(1,9) AS a;
INSERT 0 9
postgres=#
postgres=# SELECT * FROM local_hoge;
 key |               data
-----+----------------------------------
   1 | 89519f06939fe5d8109a89b0e81c2b2c
   2 | 4ca3212f5452aff3650c8e91af765c7e
   3 | f3c4dd1f3e8a2e8b9363f9baba5d4026
   4 | 7863ad08269ec451d25e0c9689dfdd3b
   5 | 63b2f56205847bb07d94ac7f7d320da6
   6 | e131864353b16e6c34e0c8f53a9c0706
   7 | 3d76e8d5891656cd97a0b9f2f3c5298a
   8 | 1e7235bba8505e740067f4141ed50a70
   9 | 0588257b0d37580295f5c391b0c6623b
(9 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_1;
 key |               data
-----+----------------------------------
   1 | 89519f06939fe5d8109a89b0e81c2b2c
   2 | 4ca3212f5452aff3650c8e91af765c7e
   3 | f3c4dd1f3e8a2e8b9363f9baba5d4026
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_2;
 key |               data
-----+----------------------------------
   4 | 7863ad08269ec451d25e0c9689dfdd3b
   5 | 63b2f56205847bb07d94ac7f7d320da6
   6 | e131864353b16e6c34e0c8f53a9c0706
(3 rows)

postgres=#
postgres=# SELECT * FROM local_hoge_3;
 key |               data
-----+----------------------------------
   7 | 3d76e8d5891656cd97a0b9f2f3c5298a
   8 | 1e7235bba8505e740067f4141ed50a70
   9 | 0588257b0d37580295f5c391b0c6623b
(3 rows)

postgres=#
postgres=# UPDATE local_hoge SET key = 7 WHERE key = 6;
ERROR:  new row for relation "local_hoge_2" violates partition constraint
DETAIL:  Failing row contains (7, e131864353b16e6c34e0c8f53a9c0706).

上記の通り、ローカルのパーティションテーブルにおいて、パーティションキーを更新した際の子テーブル間のレコードの移動は、PostgreSQL 11 から実装されている機能 (PostgreSQL 11 で強化された機能) になっています。

■最後に

今回は、PostgreSQL 11 にて外部テーブルを利用したパーティションテーブルと、ローカルで作成した (外部テーブルを利用せず、同一サーバ上で作成した) パーティションテーブルの動作を違いを検証してみました。

前述した通り、ローカルのパーティションテーブルにおけるパーティションキー更新時の子テーブル間のレコードの移動は、PostgreSQL 11 で実装 (強化) された機能となっており、バージョンが上がる毎に、少しずつ宣言的パーティショニングの機能が強化されています。

宣言的パーティショニングはユーザの期待も高く、注目されている機能であるため、今後のバージョン (PostgreSQL 12 以降) での更なる機能強化にも期待できるのではないでしょうか。

アバター画像
About サイオステクノロジーの中の人 41 Articles
サイオステクノロジーで働く中の人です。
ご覧いただきありがとうございます! この投稿はお役に立ちましたか?

役に立った 役に立たなかった

0人がこの投稿は役に立ったと言っています。


ご覧いただきありがとうございます。
ブログの最新情報はSNSでも発信しております。
ぜひTwitterのフォロー&Facebookページにいいねをお願い致します!



>> 雑誌等の執筆依頼を受付しております。
   ご希望の方はお気軽にお問い合わせください!

Be the first to comment

Leave a Reply

Your email address will not be published.


*


質問はこちら 閉じる
